IP67 5 To 1 Branch Connector PV Connector Male And Female For Solar Panel System

No review yet. Write Review
Regular price
$8.99 USD
Regular price
Sale price
$8.99 USD
Shipping calculated at checkout.

IP67 5 To 1 Branch Connector PV Connector Male And Female For Solar Panel System

Specification

Insulation Material GE PPO
Rated Voltage TUV 1000 DC/ UL 600V DC
Test Voltage 6KV (50 Hz, 1Min)
Contact Material  Copper, tin plated
Contact Resistance Less than 0.5 m ohm
Degree of Protection IP68
Pollution Degree 2
Protection Class Class II
Flame Class UL 94-V0
Plug Force Less than 50N
Withdrawal Force More than 50N
Ambient Temperature Range -40 ~ +90
Compatible Cable Cross Sections Solar Cable 2.5mm²,4.0mm² and 6.0mm² (14awg,12awg,10awg)
Pin Dimention 4.0mm
