Vendor : ECGSOLAX

Sku : MIN-3K

3000W DC 24V AC 220V All-in-One MPPT Solar Inverter Charger

No review yet. Write Review
Regular price
$239.00 USD
Regular price
$299.00 USD
Sale price
$239.00 USD
Shipping calculated at checkout.

Description

This ECGSOLAX hybrid charge inverter is a combination of a solar inverter and a battery inverter into a single piece of equipment that can intelligently manage power from your solar panels, solar batteries, and the utility grid at the same time.



Features

1.Pure sine wave inverter
2.Programmable supply priority for PV , battery or Grid
High PV input voltage range(55~450VDC)
3.Built-in Max 110A(3.6KW&6.2KW) MPPT solar charge
4.Compatibe with lithium-ion battery
5.Support BMS communication with Lithium battery
6.Smart battery charge design to optimize battery life
7.Overload,high temperature,inverter output short circuit protection
8.Cold start function
9.Intelligent fan speed adjustment
10.Built-in anti-dusk kit for harsh enviromen(optional)
11.WIFI&GPRS available for IOS and android

Hybrid Solar Inverter 12V 24V 3.2KW 3KW 1.8KW Pure Sine Wave Inverter Off Grid Build in 80A MPPT Charger Max PV 450V with WIFI

Specification

MODEL MIN-3K
Rated Power 3200VA/3000W
INPUT
Voltage 230VAC
Selectable Voltage Range 170-280VAC(for personal computers)  90-280VAC(for home appliances)
Frequency Range 50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode) 230VAC±5%
Surge power 6400VA
Transfer Time 10ms (for personal computers)        20ms (for home appliances)
Wave form Pure Sine Wave
BATTERY & AC CHARGER
Battery Voltage 24VDC
Floating Charge Voltage 27VDC
Overcharge Protection 31VDC
Maximum charge current 60A
SOLAR CHARGER
MAX.PV Array Power 3000W
MPPT Range@ Operating Voltage 55-450VDC
Maximum PV Array Open Circuit Voltage 450VDC
Maximum Charging Current 80A
Maximum Efficiency 98%
PHYSICAL
Dimension.D*W*H(mm) 405X286X98MM
Net Weight (kgs) 5.0kg
Communication Interface RS232/RS485(Standard)
 GPRS/WIFI(Optional)
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Operating Temperature -10°C to 55°C
Storage Temperature -15°C to 60°C
