Vendor : ECGSOLAX

Sku : MIN-1K

1000W DC 12V AC 220V All-in-one Solar Inverter charger

No review yet. Write Review
Regular price
$159.00 USD
Regular price
$199.00 USD
Sale price
$159.00 USD
Shipping calculated at checkout.

INTRODUCTION

This is a multi-function inverter/charger,combining functions of inverter solar charger and battery charger to offer uninterruptible power support with portable size.Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current AC/solar charger priority,and acceptable input voltage based on different applications.

Features
·Pure sine wave inverter
·Configurable input voltage range for home appliances and personal computers via LCD setting Configurable battery charging current based on applications via LCD setting Configurable AC/Solar Charger priority via LCD setting
·Compatible to mains voltage or generator power
·Auto restart while AC is recovering Overload/ Over temperature/ short circuit protection
·Smart battery charger design for optimized battery performance·Cold start function


Specification

Model MIN-1K
Phase 1-phase
Maximum PV Array Power 600W
Rated Output Power 1000W
Maximum Solar Charging Current 40A
Maximum(AC+ Solar )Charging Current 80A
PV Array MPPT Voltage Range 20~150VDC
Max. PV Array Open Circuit Voltage 150VDC
Maximum AC Input Current 30A
Nominal Operating Frequency 50/60Hz
Max AC Input Voltage 300VAC
Nominal Output Voltage 220/230/240VAC
Output Wavefrom Pure sine wave
Efficiency(DC to AC) 94%
Nominal DC Input Voltage 12VDC
PHYSICAL
Dimension,D * W * H 286*240*91
Net Weight(kgs) 3
ENVIRONMENT
Operating Temperature 10°C to 55°C

SHIPPING INFORMATION

Our goal is to offer you the best shipping options, no matter where you live. We deliver to hundreds of customers across the world every day, and we strive to provide you with services of the highest level.

1. The time frame of an order delivery is divided into two parts:
  • Processing time: 3-7 Days
  • Shipping time: 14~30 Days

2. Shipping methods: USPS,DHL, FeDex etc.
3. Shipping fee:

  • The shipping fee will be changed according to every pacel's weight.



Note: Affected by Covid-19, there will be some delay on the delivery.
