Epever Tracer AN 30 Amp DC 12V/24V Auto MPPT Solar Charger Controller

No review yet. Write Review
Normaler Preis
$89.99 USD
Normaler Preis
$169.00 USD
Verkaufspreis
$89.99 USD
Shipping calculated at checkout.

Description

EPEVER  MPPT Solar Charger Controller 30Amp DC 12V/24V Auto has a wide battery system voltage range from 8V to 32V, it can work with Lead-acid(Seal,Flood,Gel)and Lithium-ion batteries, quickly track the maximum power point of the PV array and obtain the maximum energy from solar modules under any conditions even cloudy day.



Features

1.Advanced MPPT technology, with efficiency no less than 99.5%
2.Ultra-fast tracking speed and guaranteed tracking efficiency
3.Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time
4.Wide MPP operating voltage range
5.High quality components, perfecting system performance, with maximum conversion efficiency of 98%
6.Accurate recognition and tracking of multiple-peaks maximum power point
7.International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life
8.Charging power and current limitation function
9.Compatible with lead-acid and lithium-ion batteries
10.Battery temperature compensation function
11.Real-time energy statistics function
12.Overheating power reduction function
13.Multiple load work modes
14.The communication port adopts professional protection chip, which can provide 5VDC power supply, and has over-current and short-circuit protection.
15.With RS-485 communication bus interface and Modbus communication protocol, it is available to meet various communication requirements in different situations.
16.Monitor and set the parameters via mobile phone APP or PC software
17.Full-load operation without any drop in capacity within the range of working environment temperature
18.Extensive electronic protection



Specification

Model Tracer3210AN
System nominal voltage 12/24VDC Auto
Rated charge current 30A
Rated discharge current 30A
Battery voltage range 8~32V
Battery Type Lead-acid(Seal,Flood,Gel)and Lithium-ion batteries
Max. PV open circuit voltage 100V
MPP voltage range (Battery voltage +2V)~72V
Max. PV input power 390W/12V
780W/24V
Self-consumption ≤12mA
Discharge circuit voltage drop ≤0.23V
Temperature compensate -3mV/°C/2V (Default)
Grounding Common negative
RS485 interface 5VDC/100mA
LCD backlight time 60S (Default)
Working environment temperature -25°C~+50°C
Storage temperature range -20°C~+70°C
Relative humidity ≤95%, N.C
Dimension 228x164x55 mm
Weight 0.25 kg
Mounting dimension 170x164 mm
Mounting hole size Φ5mm
Terminal 6AWG(16mm2)
Recommended cable 8AWG(10mm2)
