30Amp 12V/24V Auto PWM Solar Charge Controller

Regulärer Preis
Regulärer Preis
Translation missing: de.general.accessibility.unit_price_separator

This controller is a intelligent, multi-purpose solar charge and discharge controller. Fixed LCD display with a very friendly interface is used in this product; various control parameters can be flexibly set, fully meet your various application requirements. This is NEW Solar Controller ,It can fully meet your home Photovoltaic system(including home lighting system)requirements.It can automatically recognize 12V and 24V Lead acid ,Gel battery.

1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 4-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
5.Dual mosfet Reverse current protection ,low heat production.

Battery Voltage: 12V 24V Auto
Charging Current: 30A
Discharging Current: 10A
Max Solar Input: 50V(for 24V battery) 25V(for 12V battery)
Equalization: 14.4V(Sealed) 14.2V(Gel) 14.6V(Flood)
Float Charge: 13.7V(defaul,adjustable)
Discharge Stop: 10.7V(defaul,adjustable)
Discharge Reconnect: 12.6V(defaul,adjustable)
Charge Reconnect: 13V
Voltage of Open Light: Solar Panel 8V(Light lights delay)
Voltage of Close Light: Solar Panel 8V(Light off delay)
USB Output: 5V/3A
Self-consume: <10mA
Operating Temperature: -35°C~+60°C
Size: 133.5*70*35mm

Please let us know if you have any questions about this product.
